Traxxas TRX4 Land Rover Defender 1/10 Crawler Black RTR

The Traxxas TRX-4 Scale and Trail Crawler is loaded with innovation that instantly obsoletes the status quo with exciting new features, versatility, and capability. In other words, we built it the Traxxas way, rugged, powerful, and ready for fun!

Underneath the authentic scale look is a machine built for extreme off-road capability that takes you to new places and new adventures. Exclusive portal axles deliver maximum ground clearance that dramatically turns “no way” into “no problem.” Whether you are enjoying outdoor trails or getting technical on the rocks, the remote-locking front and rear differentials and high/low range transmission provide unmatched driving versatility.

TRX-4 Features:

Officially Licensed Land Rover Defender Body

Injection-molded scale details including grill, snorkel, and side mirrors

Rugged, functional roll cage

Tough fender flares

Front bumper with tow hooks and replica winch

Rear bumper with scale accessories and functional spare tire

Full Nylon composite wheel wells and floor pans

Trail-tuned XL-5 HV Waterproof Electronic Speed Control

Fully waterproof design

Five drive profiles

-Sport Mode — forward / brake / reverse

-Race Mode — forward / brake / no reverse

-Training Mode™ — 50% forward / 100% brake / 50% reverse (patented)

-Trail Mode — forward / brake / reverse / with trail-tuned drag brake in neutral

-Crawl Mode — forward / instant reverse – no neutral with 100% hill holding brake

Traxxas EZ-Set® one-button setup

Large, efficient heat sink

Wide voltage latitude 6–7 cell NiMH (7.2–8.4V) and 2–3S LiPo (7.4–11.1V)

Two-stage low voltage protection (LVD)

Motor

Powerful Titan™ 21T reverse rotation motor with internal cooling fan

Precision, preset gear mesh adjustments

Motor retention separate from gear mesh

Portal Axles

Increase ground clearance (3.14”)

Eliminate torque twist

Steel gears

Improve axle geometry and reduce strain on driveshafts

Rigid Steel Frame

1.5mm thick steel frame rails increase torsional rigidity

Innovative design allows four wheelbase positions (300mm, 312mm, 324mm, 336mm)

Adjustable rear shock tower positions for SWB and LWB configurations

Bumpers adjust fore and aft

Rugged rock rails adjust for width

Wire routing clips integrated into frame rails

Drivetrain

Full-time shaft driven 4-wheel drive

Tough 6mm stub axles

Steel front CV driveshafts

Hardened steel rear axle shafts

Remote locking steel gear differentials with cable-actuation

Steel gear transfer case

Innovative Battery Compartment

Hinged battery strap allows quick and easy battery access

No pins to lose

Accommodates different height batteries

Accepts full-size long battery packs

Integrated compartment accepts smaller 1/16 scale batteries (with optional strap)

Transmission

Two speed high/low range with remote shifting

Dual horizontal shafts

Twin friction plate slipper clutch

Easily removed for servicing

Steering

Chassis mounted 2075X metal gear digital servo

Superior 45° steering angle

Direct steering (no servo saver)

Steering geometry corrected for bump steer

Suspension

Front — 3 link with panhard

Rear — Triangulated 4 link

Heavy-duty rod ends with steel hollow balls

5mm diameter steel link rods with 4mm threaded ends

Aluminum GTS Shocks

Oil-filled coilover GTS shocks exclusive to TRX-4 chassis

Silver-anodized aluminum bodies

Threaded bodies with collars easily adjust ride height

Silky smooth damping for the toughest trails

O-ring cap seal and dual X-ring shaft seals

Wheels and Tires

1.9” Canyon Trail tires with trail-tuned foam inserts

Pre-glued and mounted to tough black scale wheels

Trail-tuned S1 rubber compound

12mm steel hex

Transmitter

TQi™ 2.4GHz 4-channel transmitter

Traxxas Link enabled

Telemetry ready #6533 5-channel micro receiver with failsafe

Automatically stores and loads settings for up to 30 Traxxas Link-enabled models

Exclusive Cruise Control feature for extended trail driving

Adjustable steering and throttle sensitivity (exponential)

Adjustable steering and throttle endpoints

High 13ms frame rate and near-zero latency for responsive control

Patented O-Ring sealed watertight receiver box keeps the micro receiver dry

Sealed Ball Bearings

Hex hardware with rust-resistant black oxide coating
