Iflight XING2 2809 1250KV FPV Motor Unibell

Features

5mm titanium alloy shaft, our strongest prop shaft ever!

Crash resistant 7075 aluminum bell

Smooth and long-lasting NSK 11x5x5 bearings

Center slotted N52H curved arc magnets

XING O-ring bearing gap protection

Motor wires protector

Dynamically balanced

Specifications

Model: XING2 2809 Motor

KV: 1250KV

Weight(included wire): 60.7g

Dimension: ?35.33*21.7mm

Interphase Resistance: 65.46m?

Input Volts: 24V

Peak Current: 49.23A

Max Watt: 1147.1W

Mounting Holes: 19*19 ?3mm

Rotor Specifications: Unibell

Shaft Diameter: 4mm

Shaft Protruding Length: 15mm

Lead: 260mm/18AWG

Magnet: N52H Curved

Configuration: 12N14P

Bearing Type: NSK

Bearing Specification: ?11*?5*5

Winding: Single Strand copper winding
