E-flite 40-Amp Pro Switch-Mode BEC Brushless ESC (V2)

Key Features


?Up to 40 amps continuous current with proper air flow and 55 amps burst current (15 seconds)

?5A continuous current, 5V Switch-Mode BEC Circuit (Proper cooling and airflow required)

?Stronger BEC for support of most 3-axis stabilization systems

?Drive up to 7 analog or 6 digital standard-sized servos with the BEC

?3- to 6-cell Li-Po, 9- to 18-cell Ni-MH/Ni-Cd input voltage

?Finned heat sinks

?Programmable motor braking

?Safe power-arm mode prevents accidental starts

?Programmable low voltage cutoff with settings for 3-cell Li-Po (9V), 4-cell Li-Po (12V), 5-cell Li-Po (15V), 6-cell Li-Po (18V) or 70% of battery starting voltage

?Programmable throttle input range

?Programmable soft start for helis and airplanes

?Auto motor shut down if signal is lost or there is interference

?Programmable timing?5 user-selectable ranges to use with a large variety of brushless motors

?Utilizes new smaller Mosfet technology to minimize weight

?Radio System Power ON /OFF Switch

?Prewired connectors?E-flite EC3? connector on battery input and 3.5mm gold bullet connectors on motor output leads

Overview

E-flite? 40-Amp Pro Switch-Mode BEC Brushless ESC (V2) is a high-quality sensorless brushless electronic speed control with an integrated switch-mode BEC that is very lightweight and efficient. It can operate without the need for a separate receiver battery to power your servos and receivers, saving you weight and complication.
