DIATONE MAMBA TOKA 1606 3750KV BRUSHLESS MOTOR

Original price was: $14.99.Current price is: $10.49.

SKU: C25OB 12293 Categories: Electric Motors, Electronics

Get the Best for Less
Free Shipping Worldwide
Green products, guaranteed.
Your questions, our prompt answers.

Description
Reviews (0)

DIATONE MAMBA TOKA 1606 3750KV BRUSHLESS MOTOR -Toys Model Store

MAMBA TOKA 1606 3750KV MOTOR

Overall Dimension: ?22.2×15mm

Shaft Diameter:1.5mm

Installation hole position:12×12mm?M2

Prop: 3inch~4inch

Bearing? 5*2*2.5

Diameter:2mm

Lead Wire Size?24AWG ×150mm

Configuration:9N12P

Magnet Wire: Class H?220? Enameled Wire

Stator Diamter?16mm

Stator Height:6mm

Rated Voltage: 3~4S (12.6V~16.8V)

Peak Current: 21.1A

ldle Current?9v/0.8A

Maximum Power: 338W

Internal Resistance?114?
